EVOline One USB-A & USB-C Charger with Lid – Choice of Colour
EVOline One compact double USB charger with a rotating lid, one USB-A port and one USB-C port. Available in six lid and housing finish combinations, with a shared output of 5V, 2.1A and 10.5W maximum. Requires a 54mm cut-out and a minimum installation depth of 50mm.
EVOline One double USB charger with a rotating lid, available in six lid and housing finish combinations. The unit has one USB-A port and one USB-C port, providing discreet and space-saving charging access for worktops, desks and other furniture surfaces. It is suitable for horizontal or vertical installation and requires a 54mm diameter cut-out.
Key Benefits:
- Compact, space-saving charging solution
- One USB-A port and one USB-C port
- Rotating lid conceals the charging ports when not in use
- Suitable for horizontal or vertical installation
- Choice of six lid and housing finish combinations
- Flexible cable entry enables a minimum installation depth of 50mm
Available Finishes:
- Black lid with black housing
- White lid with white housing
- Brushed stainless-steel lid with black housing
- Brushed stainless-steel lid with white housing
- Brass-effect lid with black housing
- Brass-effect lid with white housing
Technical Details:
- USB ports: 1 × USB-A and 1 × USB-C
- Input voltage: 110–240V AC
- Input frequency: 50–60Hz
- Shared output voltage: 5V DC
- Shared output current: 2.1A maximum
- Shared output power: 10.5W maximum
- Overall diameter: 73mm
- Cut-out diameter: 54mm
- Minimum installation depth: 50mm
- Installation thickness with standard wing clamps: 9–25mm
- Protection rating: IP20
Supplied Parts:
- EVOline One USB charger with rotating lid
- 3m supply cable with 13A UK plug
- Standard wing clamps
Additional Clamp Option:
- Wing clamps for installation thicknesses of 21–38mm are available on request
Warranty:
- 1-year warranty
Please Note:
- The 2.1A and 10.5W maximum output is shared between the USB-A and USB-C ports
- Do not cut the installation opening before receiving the product, as this will help ensure the correct fit
| Manufacturer | EVOline |
|---|---|
| Number of sockets | 0 Socket |
| Wireless Charging | No |
| USB - A | Yes - 1x |
| USB - C | Yes - 1x |
| Approvals | UKCA Mark |
| Stock status | In stock |
|---|---|
| Delivery time | 1-3 working days |
| Returns Status | Returnable in 14 days |
