Welcome Ramp Kit A, 1x Double Handrail - 120 to 480cm Lengths, Standard Height 33cm (13”)

Welcome modular wheelchair access ramp system for domestic use with a double handrail available in 6x colour combinations, that can be located either side of the ramp.

Available in a range for lengths 120cm (4ft) to 480cm (16ft).

This system offers fast assembly, by one person and can be easily transported, dismantled and re-assembled and re-used as required. Offering huge benefits over traditional concrete ramps.

Suitable for a minimum step height 12.5cm (5”) to 33cm (13”) that can be increased to a maximum height of 50cm (20”) with Leg Extensions (Product Code: WLX).

Longer ramps are ideal for higher levels. For outward opening doors and or if a rest area is required, ramp kits with platforms are also available.

Key benefits:

• The ramp is fully self-supporting making the system ideal for uPVC door thresholds
• Extremely durable construction and finish, designed for outdoor use
• Easily modified, adapted and reused
• Fast one-person install the heaviest component is 16kg
• The Gripdeck wearing surface is friendly to pets, high heels and has a superb grip when wet
• Built to last, the system has a huge 400kg capacity
• The handrails are pre-galvanised steel with a powder coated finish that is durable yet ‘warm to the touch’
• The height adjustable legs can be adjusted to suit ground variations and a range of step heights
• Materials: Aluminium and galvanised steel
• Designed, manufactured and stocked in the UK for next-day delivery

Choice of 6x handrail colour combinations:

• Original Graphite: Universally appealing soft dark grey - Posts and upper rails
• Garden Green: A traditional deep green, perfect for garden environments - Posts and upper rails
• Heritage Brown: A dark, rich brown to complement traditional and heritage buildings - Posts and upper rails
• Safety Yellow: A rich yellow, perfect for visual safety needs – Posts and upper rails
• Safety Yellow horizontal rails: With posts in either Garden Green or Heritage Brown
• All rails have Black plastic end caps and Black straps securing the horizontal rail
• Colour matched Bowends also available for the ends of the Double handrails (Product Code: WRBE) order separately

Technical specification:

• Range of lengths select above: 120cm (4ft) to 480cm (16ft)
• Internal ramp width - 90cm (35”)
• External ramp width - 100cm (39.4”)
• Kerb height - 8cm (3”)
• Mid rail height - 60cm (24”)
Upper rail height - 90cm (35”)
• Ramp system - Minimum installed height 12.5cm (5”)
• Ramp system - Maximum installed height 33cm (13”)
• Leg Extensions (Product Code: WLX) order separately in pairs - Maximum installed height 50cm (20”)

Warranty:

• 10-year Design life

Manufacturer product codes:

• WRA12-D; WRA18-D; WRA24-D; WRA30-D; WRA36-D; WRA42-D; WRA48-D
