Linear Drains for Vinyl Wetroom Floors
Linear Drains for Vinyl Wetroom Floors
Linear drains for vinyl wetroom floors are specifically designed to create a secure, watertight connection between the drainage system and sheet vinyl flooring, providing reliable long-term performance in accessible and level-access shower installations.
Unlike tiled wetrooms, sheet vinyl flooring must be mechanically sealed to the drain using a clamping-ring system. This creates a waterproof connection between the floor covering and the drain body, preventing water from penetrating beneath the vinyl and protecting the subfloor.
Linear vinyl drains allow the shower floor to be formed with a single-direction gradient, making installation simpler than traditional centre wastes. This design also provides smooth, predictable floor falls that are particularly beneficial for wheelchair users, seated showering and assisted living environments.
Vinyl wetroom flooring is widely specified because it offers:
- A seamless, hygienic floor finish
- Excellent slip-resistant properties
- Easy cleaning and low maintenance
- Long-term durability in high-use environments
Linear vinyl drains are commonly specified for:
- Domestic accessible bathrooms
- Hospitals and healthcare facilities
- Care homes and assisted living accommodation
- Social housing and Disabled Facilities Grant (DFG) adaptations
To achieve reliable performance, careful specification and installation are essential. Key considerations include:
- Secure clamping of the sheet vinyl flooring
- Correct floor gradients towards the drain
- Efficient drainage capacity for the shower flow rate
- Long-term waterproofing and tanking
For commercial, healthcare and public environments, lockable and tamper-resistant grates are also available to improve safety, prevent unauthorised removal and reduce maintenance requirements.
All linear vinyl drainage systems should be installed in accordance with UK Building Regulations Approved Document M and BS 8300, helping to deliver safe, accessible and durable wetroom installations.
Can linear drains be used with vinyl flooring?
Yes. Linear drains are available with dedicated clamping-ring systems that securely seal sheet vinyl flooring to the drain body, creating a fully waterproof wetroom installation.
What is a clamping drain system?
A clamping drain system uses a mechanical clamping ring to firmly secure the sheet vinyl flooring to the drain body. This creates a watertight seal that prevents moisture from passing beneath the floor covering.
Are vinyl wetrooms suitable for accessibility?
Yes. Vinyl wetrooms are widely used in accessible bathrooms because they provide a seamless, slip-resistant surface that is easy to clean and well suited to wheelchair users, people with reduced mobility and care environments.
How do you waterproof a vinyl wetroom drain?
A vinyl wetroom drain is waterproofed by securely clamping the sheet vinyl flooring to the drain body using a compatible clamping-ring system. Correct installation, waterproofing and floor gradients are essential to ensure long-term performance and prevent water ingress.
-
Purus Line Living Plus 600mm Linear Drain, Vinyl Floor, Stainless Steel Chess Design Grid - Outlet ChoiceProduct Code: 53303-05As low as £404.40 £337.00
In stock
Next working day if ordered by 1.30pm
-
Purus Line Living Plus 800mm Linear Drain, Vinyl Floor, Stainless Steel Chess Design Grid - Outlet ChoiceProduct Code: 53315-17As low as £469.20 £391.00In stock
Next working day if ordered by 1.30pm
-
Purus Line Living Plus 900mm Linear Drain, Vinyl Floor, Stainless Steel Chess Design Grid – Outlet ChoiceProduct Code: 53321-23As low as £500.40 £417.00In stock
Next working day if ordered by 1.30pm
-
Purus Line Living Plus 700mm Linear Drain, Vinyl Floor, Stainless Steel Chess Design Grid - Outlet ChoiceProduct Code: 53309-11As low as £464.40 £387.00In stock
Next working day if ordered by 1.30pm
-
Purus Line Living Plus 1000mm Linear Drain, Vinyl Floor, Stainless Steel Chess Design Grid – Outlet ChoiceProduct Code: 53327-29As low as £526.80 £439.00In stock
Next working day if ordered by 1.30pm
-
Purus Line Living Plus 600mm Linear Drain, Vinyl Floor, PVD Brushed Brass Chess Design Grid - Outlet ChoiceProduct Code: 53303-05BBAs low as £638.40 £532.00Available to order
10-12 working days
-
Purus Line Living Plus 700mm Linear Drain, Vinyl Floor, PVD Brushed Brass Chess Design Grid - Outlet ChoiceProduct Code: 53309-11BBAs low as £714.00 £595.00Available to order
10-12 working days
-
Purus Line Living Plus 800mm Linear Drain, Vinyl Floor, PVD Brushed Brass Chess Design Grid – Outlet ChoiceProduct Code: 53315-17BBAs low as £781.20 £651.00Available to order
10-12 working days
-
Purus Line Living Plus 900mm Linear Drain, Vinyl Floor, PVD Brushed Brass Chess Design Grid – Outlet ChoiceProduct Code: 53321-23BBAs low as £828.00 £690.00Available to order
10-12 working days
-
Purus Line Living Plus 1000mm Linear Drain, Vinyl Floor, PVD Brushed Brass Chess Design Grid – Outlet ChoiceProduct Code: 53327-29BBAs low as £870.00 £725.00Available to order
10-12 working days
-
Purus Line Living Plus 600mm Linear Drain, Vinyl Floor, PVD Matt Black Chess Design Grid - Outlet ChoiceProduct Code: 53303-05MBAs low as £638.40 £532.00Available to order
10-12 working days
-
Purus Line Living Plus 700mm Linear Drain, Vinyl Floor, PVD Matt Black Chess Design Grid - Outlet ChoiceProduct Code: 53309-11MBAs low as £714.00 £595.00Available to order
10-12 working days
-
Purus Line Living Plus 800mm Linear Drain, Vinyl Floor, PVD Matt Black Chess Design Grid – Outlet ChoiceProduct Code: 53315-17MBAs low as £781.20 £651.00Available to order
10-12 working days
-
Purus Line Living Plus 900mm Linear Drain, Vinyl Floor, PVD Matt Black Chess Design Grid – Outlet ChoiceProduct Code: 53321-23MBAs low as £828.00 £690.00Available to order
10-12 working days
-
Purus Line Living Plus 1000mm Linear Drain, Vinyl Floor, PVD Matt Black Chess Design Grid - Outlet ChoiceProduct Code: 53327-29MBAs low as £870.00 £725.00Available to order
10-12 working days
